The Matrix 120 is the smallest ultra-compact industrial 2D imager range in the market to fit any integration space and the smallest compact 2D imager with embedded Ethernet connectivity

Sensor	CMOS sensor with Global Shutter/WVGA - 752x480 px CMOS sensor with Global Shutter/1.2 MP - 1280x960 px
Frame Rate	up to 57 full-frame/s (WVGA model) , up to 36 full-frame/s (1.2 MP model)
Illumination	White Internal Illuminator
Focusing System	Manual adjustment in three precalibrated positions (45, 70, 125mm - WVGA ; 45, 80, 125mm - 1.2 MP)
Polarizer filter	Available on dedicated models
Readable Symbologies	Omnidirectional reading on any of the following codes: 1D Codes: all standard 1 dimensional symbologies 2D Codes: Data Matrix, QR Code, Micro QR, Maxicode, Aztec, Dot Code Postal Codes: Royal Mail, Japan Post, Planet, Postnet and many more Digimarc Barcode: DWCODE™
Operating Mode	Continuous, One Shot, Phase mode
Power Supply Voltage	5-30 VDC;
Max Power Consumption	1.6 to 2.4 W
Protection Class	IP65
Environmental compliance	Complies to EU RoHS
Warranty	2-Year Factory Warranty

HIGHLIGHTS

• Ultra compact dimensions for easy integration

• WVGA – 1.2 MP and wide angle models

• Smart user selectable focus for high application flexibility

• Digimarc Barcode reading technology for added value decoding applications

• Embedded Ethernet connectivity

• Serial and USB options on the same model

• ESD versions for electronic applications

• Polarized Version for 90° mounting and reflecting surfaces

• Models equipped with shorter output cables (100mm of length) for easier integration in OEM machines

• Top industrial grade: IP65; operating temperatures: 0-45 ºC / 32 – 133 ºF

• DL.CODE software configurator for outstanding ease of setup

• Xpress, Datalogic’s ‘Green Spot’ technology and intuitive HMI for top ease of use

APPLICATION

• Electronics: Track and trace PCB board manufacturing

• Factory Automation: Print & Apply – label verification

• Factory Automation: Food & Beverage – traceability

• OEM: Kiosks: ticketing machine

• Healthcare: Clinical Lab – vials identification

• Chemical and biomedical analysis machine

Model

CODE	ULTRA-COMPACT INDUSTRIAL 2D IMAGER
937800000	MATRIX 120 210-000 WVGA SER+USB STD
937800002	MATRIX 120 210-001 WVGA SER+USB ESD
937800001	MATRIX 120 210-010 WVGA SER+ETH STD
937800003	MATRIX 120 210-011 WVGA SER+ETH ESD
937800052	MATRIX 120 210-050 WVGA SER+USB STD SC
937800053	MATRIX 120 210-060 WVGA SER+ETH STD SC
937800006	MATRIX 120 210-100 WVGA SER+USB 1D
937800007	MATRIX 120 210-110 WVGA SER+ETH 1D
937800004	MATRIX 120 310-001 1.2MP SER+USB ESD
937800005	MATRIX 120 310-011 1.2MP SER+ETH ESD
937800045	MATRIX 120 310-01A 1.2MP SER+ETH
937800008	MATRIX 120 311-000 1.2MP SER+USB WA
937800014	MATRIX 120 311-005 1.2 SER+USB WA PLZR
937800009	MATRIX 120 311-010 1.2MP SER+ETH WA
937800015	MATRIX 120 311-015 1.2 SER+ETH WA PLRZ
937800054	MATRIX 120 311-050 1.2MP SER+USB WA SC
937800056	MATRIX 120 311-055 1.2 SER+USB WA PLZ SC
937800055	MATRIX 120 311-060 1.2MP SER+ETH WA SC
937800057	MATRIX 120 311-065 1.2 SER+ETH WA PLZ SC
937800010	MATRIX 120 311-100 1.2MP SER+USB WA 1D
937800011	MATRIX 120 311-110 1.2MP SER+ETH WA 1D
937800040	MATRIX 120 311-205 SER+USB AGV
937800041	MATRIX 120 311-215 SER+ETH AGV
